HOME-PRODUCTS-Off Road

JD785

High Durability

High Strength

Tear and Cut Resistance

Anti Impact

Adapt to Various Road Conditions

Good Self-cleaning on Pattern

Suitable

Origin		Size	PR	LI/ SS		Standard Rim	Max. Load				Pressure				Tread Depth (mm)	Overall Diameter (mm)	Section Width (mm)
Origin							(kgs)		(lbs)		(kPa)		(PSI)
CN	VN						S	D	S	D	S	D	S	D
·		7.50R16LT	14	122/118	D	6.00G	1500	1320	3310	2910	770	770	110	110	18.5	815	215
·		8.25R16LT	18	128/124	D	6.50H	1800	1600	3970	3530	770	770	110	110	20.5	865	235
·		8.25R20	16	139/137	D	6.5	2430	2300	5360	5070	930	930	135	135	20.0	974	236
·		9.00R20	18	144/142	D	7.0	2800	2650	6170	5840	900	900	130	130	22.0	1030	259
·		10.00R20	20	149/146	D	7.5	3250	3000	7165	6610	930	930	135	135	23.5	1065	278
·		11.00R20	18	152/149	D	8.0	3550	3250	7830	7170	930	930	135	135	24.0	1096	293
·	·	12.00R20	22	158/155	D	8.5	4250	3875	9370	8540	970	970	140	140	24.0	1136	315

S=Single D=Dual;  1inch=25.4mm 1kPa=0.142psi 1KG≈2.2lbs

1inch=25.4mm 1kPa=0.142psi 1KG≈2.2 Ibs
