HOME-PRODUCTS-Regional

JD575

High Speed

High Durability

Excellent Grip

Excellent traction

High wear resistance

Suitable

Origin		Size	PR	LI/ SS		Standard Rim	Max. Load				Pressure				Tread Depth (mm)	Overall Diameter (mm)	Section Width (mm)
Origin							(kgs)		(lbs)		(kPa)		(PSI)
CN	VN						S	D	S	D	S	D	S	D
●	●	205/75R17.5	14	124/122	L	6.00	1600	1500	3525	3315	750	750	110	110	15	753	204
●	●	215/75R17.5	16	135/133	L	6.00	2180	2060	4805	4540	860	860	125	125	15	767	211
	●	235/75R17.5	16	132/130	M	6.75	2000	1900	4410	4190	760	760	110	110	15	797	233
●	●	235/75R17.5	18	143/141	L	6.75	2725	2575	6005	5675	860	860	125	125	15	797	233
●		225/70R19.5	14	128/126	L	6.75	1800	1700	3970	3750	760	760	110	110	15	817	226
	●	245/70R19.5	16	136/134	M	7.50	2240	2120	4940	4675	830	830	120	120	15.5	839	248
●	●	245/70R19.5	18	144/142	J	7.50	2800	2650	6175	5840	900	900	130	130	15.5	839	248
●		265/70R19.5	18	143/141	J	7.50	2725	2575	6005	5675	900	900	130	130	15.5	867	262
●		285/70R19.5	18	146/144	L	8.25	3000	2800	6610	6175	900	900	130	130	16	895	283
●		285/70R19.5	18	150/148	K	8.25	3350	3150	7390	6945	900	900	130	130	16	895	283
●		255/70R22.5	16	140/137	L	7.50	2500	2300	5510	5070	830	830	120	120	19.5	930	255
●		275/70R22.5	16	148/145	M	8.25	3150	2900	6945	6395	900	900	130	130	20	958	276
●		295/60R22.5	18	150/147	L	9.00	3350	3075	7390	6780	900	900	130	130	19	926	292
●	●	295/80R22.5	18	152/149	L	9.00	3550	3250	7825	7165	900	900	130	130	22	1044	298
●	●	315/60R22.5	18	152/148	L	9.75	3550	3150	7825	6945	900	900	130	130	20	950	313
●	●	315/70R22.5	18	156/150	L	9.00	4000	3350	8820	7385	900	900	130	130	20	1014	312
	●	315/80R22.5	18	156/150	L	9.00	4000	3350	8820	7385	900	900	130	130	22.5	1076	312
●	●	315/80R22.5	20	156/153	K	9.00	4000	3650	8820	8050	850	850	120	120	22.5	1076	312

S=Single D=Dual; 1inch=25.4mm 1kPa=0.142psi 1KG≈2.2lbs

1inch=25.4mm 1kPa=0.142psi 1KG≈2.2 Ibs
